Moduł Bluetooth. Części grzejnika (200W), Skrzynka rozdzielcza (do połączenia równoległego)
Model
HV RESS- 72
Moduł baterii
51.2V 72Ah(3.68KWH)
Liczba modułów baterii
4
5
6
7
8
Całkowita energia [kWh]
14.7
18.4
22.0
25.7
29.4
Napięcie nominalne[Vdc]
204.8
256
307.2
358.4
409.6
Zakres napięcia [Vdc]
160~240
200~300
240~360
280~420
320~480
Maks. Prąd ładowania [A]
50
Maks. Prąd rozładowania [A]
50
Prąd rozładowania impulsowego
100A/10s
Maks. Moc inwertera[W]
10000
12800
15360
17920
20480
Zakres temperatur pracy
Ładowanie:0~+55°C;Rozładowanie:-20~+55C
Wilgotność robocza
Model
HV RESS- 100
Moduł baterii
51.2V 100Ah(5.12KWH)
Liczba modułów baterii
4
5
6
7
8
Całkowita energia [kWh]
20.5
25.6
30.7
35.8
40.9
Napięcie nominalne[Vdc]
204.8
256
307.2
358.4
409.6
Zakres napięcia [Vdc]
160~240
200~300
240~360
280~420
320~480
Maks. Prąd ładowania [A]
50
Maks. Prąd rozładowania [A]
50
Prąd rozładowania impulsowego
100A/10s
Maks. Moc inwertera[W]
10000
12800
15360
17920
20480
Zakres temperatur pracy
Ładowanie:0~+55°C;Rozładowanie:-20~+55C
Wilgotność robocza
0~95% RH(Bez kondensacji)
Interfejs komunikacyjny
CAN*1,DI*1,DO*2
Zalety baterii litowych
1. Wysoka gęstość energii: Wysoka gęstość energii baterii litowych może zapewnić więcej mocy, umożliwiając wydajniejszą pracę turbinom nowej energii. 2. Długa żywotność: Długa żywotność baterii litowych zmniejsza częstotliwość wymiany baterii, zmniejszając tym samym koszty konserwacji. 3. Dobre bezpieczeństwo: W porównaniu z innymi typami baterii, baterie litowe mają lepsze parametry bezpieczeństwa, co może skutecznie zapobiegać pożarom i innym wypadkom. 4. Szybki czas reakcji: Baterie litowe mają krótki czas reakcji i mogą szybko dostarczyć wymaganą energię elektryczną, umożliwiając szybsze uruchamianie i zatrzymywanie turbin nowej energii. 5. Przyjazne dla środowiska: Baterie litowe są przyjaznym dla środowiska rodzajem baterii, który nie zanieczyszcza środowiska.
Since installing this variable-pitch wind turbine, the battery hasn’t run low again. Before, I used to worry whenever we had consecutive overcast days and light winds in the winter, but now it can even charge the battery in low winds. Best of all, it doesn’t suddenly start screeching during gusts, so it doesn’t disturb my family’s sleep. The installer also mentioned that variable-pitch turbines are easier to calibrate than fixed-pitch ones. I give it five stars!
I run a small dairy farm in northern Norway, far from the power grid. A few years ago, I installed solar panels and a Deye inverter, but the solar system basically stops working in winter, and the diesel generator was costing me a fortune. This year, I added this variable-pitch wind turbine and connected it to the Deye inverter for a hybrid solar-wind system, and we haven’t had a single power outage all winter. This wind turbine starts up at low wind speeds of just 2–3 on the Beaufort scale. During blizzards, the blades automatically pitch down to slow the turbine, preventing runaway speeds, and it’s much quieter than my neighbor’s fixed-pitch model. The Deye inverter’s switching logic is smart—it prioritizes solar power when available, and automatically switches to the wind turbine when solar output drops. It’s all clearly visible on the app. Now, the diesel generator is practically idle. Wind and solar backing each other up—that’s true off-grid freedom.
“I built a small pico hydro system on the creek behind my off-grid cabin. The water head is only 3 meters and flow rate around 0.2 m³/s – too low for most generators. This axial flux coreless unit starts generating usable power at just 150 RPM. No cogging, no iron loss, and it’s silent. I’m getting 300-400W continuously, 24/7. My old induction generator would barely light an LED at that speed. Absolutely perfect for low-head hydro.”
